Automatic Diecutting Machine YAWA PRO-106
Technical Specifications:
Maximum sheet size: 1060 mm x 760 mm
Minimum sheet size: 400 mm x 360 mm
Maximum die-cutting area: 1050 mm x 750 mm
Maximum speed: 7,500 sheets per hour
Maximum pressure: 300 tons
Material thickness:
Paper: 90-2000 g/m²
Corrugated board: up to 4 mm
Die-cutting accuracy: ±0.1 mm
Hot foil stamping temperature: up to 200°C
Heating zones: 6 individually controlled zones
Total power consumption: approximately 20 kW
Machine dimensions: approximately 6,800 mm (L) x 4,200 mm (W) x 2,300 mm (H)
Weight: approximately 16,000 kg
